Product Overview
CF Moto UForce 500 / 800 Pro Snow Plow for all Years and Models
DENALI Pro Series UTV Snow Plows are ready for the snow season! Our team of engineers designed a Cadillac plow at a reasonable price so you don't have to skimp on quality to save money. This Center Mounted plow disperses the force of impact to the sturdiest part of the UTV and SxS, preventing damage to the front end or other vehicle parts from sudden impact.
Please Note: All Snow Plow Systems require a winch (not included) to raise and lower the plow blade. We recommend a VIPER Elite, Max or Midnight winch with an automatic brake. We have all these winches available for a great price.
When Ordering: Choose the color Blade you would like and the Size you need. The 72" Plow Blade is $50.00 more. You will need Pushtubes and UTV Pushtubes are added in the price. If you need a lift kit for aftermarket Skid Plates or extended Pushtubes for UTVs with Tracks, those options are loaded for you. Hydroturn Systems are an option you may want for convenience of turning your Plow from side to side from the Cab. Finally Plow Pulley Fairlead Kits are designed to take the load off the cables and will extend their life. Standard Spools and Wide Spools are to work in with the Winch you already have or want to buy.
Kit Contents:
UTV Snow Plow Blade - County / DOT Style
UTV Pushtubes
Specific Snow Plow Mount (you need to add from the cart, the price is included)
One (1) Reversible Wearbar
Rubber Flap
Rubber Flap Stabilizer Bar
Skid Feet
Plow Markers
Installation Hardware and Instructions
Blade Features:
County-style blade (curved design) cuts wet snow & throws powder; made of 12-gauge steel
Impact Resistant Reinforcement System, includes leading edge stiffener and vertical stabilizer bar
Sand-blasted powder coat with epoxy primer & TGIC Polyester top coat for corrosion protection, UV resistance and durability
High strength, high yield 3/16 thick Grade 50 steel wear bar
Angled Blade : 16 on the low side; 23 on the high side
Rubber flap & stabilizer bar with rubber flap
Height AND angle adjustable steel skid feet
3 Year Warranty
Pushtube Features:
Impact Resistant Reinforced Pivot Assembly - 2 additional support bars for maximum durability & strength
Turn system allows for easy positioning of the blade in 5 different angles - 0, 12.5°, 25°
Simple detachment system with the pull of a pin
Structural tube steel cross bar for added lateral rigidity
Quick release pins included
Pushtube Lift Kits allow plow installation on machines with skid plates, 13”-15” and 15”-17” off the ground
Extended Push Tubes are designed to be used with SxS/UTVs that have tracks
Optional Lift Kit Features:
This allows you to match your height to the ground if you have added height to your UTV / Side x Side. These can work with Extended Pushtubes if you have added tracks too.
Optional Hydroturn Features:
Hydraulic system is completely sealed for life, no need to purchase hydraulic fluid, bleed lines, maintain a reservoir level or change the fluid
Change the blade angle while driving; full radius turn in just 10 seconds
Heavy duty chrome plated ¾″ cylinder shaft
No modifications necessary - bolts directly to the Denali UTV Plow Push Tubes
Wire harness utilizes weatherproof connectors
Optional Plow Pulley Fairlead Features:
Roller
Replaces the winch fairlead during the plow season
For use with Steel AND Synthetic cables
Curved cable groove helps eliminate flattening and breaking of cable
Bolt Patterns:
Standard Spool: 3″ x 4.875″
Wide Spool: 3" x 6.67″
Sheave
Includes pulley, 1/4″ clevis hook and nylon strap
Allows greater precision when raising/lowering plow blade and increases the angle of pull
Cable
12′ length, 1/4″ diameter
Single braid, dyneema rope with galvanized steel thimble/eyelet
Denali ATV/UTV Plow Mounts
ATV Mounts $69.95
UTV Mounts $99.95
Choose ATV or UTV Plow Mount
ATV Plow Mount $69.95 - UTV Plow Mount $99.95
DENALI UTV Snow Plow Mounts are used for DENALI UTV Snow Plows. They are made of 100% laser cut 1/4″ steel and include all the
necessary hardware for mounting. Custom slotted holes allow the plow blade to hug the ground while the overall design of the side
walls are formed from the body to maximize the strength of the mount. All components of the mount are welded together to create an
impact resistant plow mount plate.
Please Note: the silver, Quick Release Pins, are NOT included with the purchase of the plow mount plate. They are available for sale separately.
Specs:
* 1/4″ steel
* 100% laser cut
* Black, industrial powder coat finish
* Includes mounting hardware and detailed instructions
Fitment:
2014-20 CFMOTO UForce 800
2016-20 CFMOTO UForce 500
Free shipping to the Lower 48
